2023 Honda Trail125

Stock #P5000789
Check Availability Hi, my name is and I'm interested in this 2023 Honda Trail 125 . I'm in the area and you can reach me at or on my phone at .
  • Status:
    New
  • Vehicle:
    2023 Honda Trail125
  • VIN:
    MLHJA6559P5000789
  • Model Number:
    CT125AMP
  • Color:
    PEARL ORGANIC GREEN
  • Stock Number:
    P5000789
  • Title:
    Clear
  • Location:
    Mid Tenn Powersports
  • Warranty:
    Manufacturer's w/ Extended Available

BRAKES

  • Front Brake Diameter (in):
    8.7
  • Front Brake Diameter (mm):
    220
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    7.5
  • Rear Brake Diameter (mm):
    190
  • Rear Brake Type:
    Drum

ENGINE

  • Bore (in):
    1.97
  • Bore (mm):
    50
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    10
  • Cooling:
    Air
  • Cylinders:
    1
  • Displacement (cc):
    124.9
  • Displacement (ci):
    7.6
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    Single-Cylinder
  • Fuel Injector Size (mm):
    24
  • Fuel Injector:
    Yes
  • Fuel Type:
    Gas
  • Starter:
    Electric / Kick
  • Stroke (in):
    2.48
  • Stroke (mm):
    63.1
  • Valve Configuration:
    SOHC
  • Valves Per Cylinder:
    2
  • Valves:
    2

EXTERIOR

  • Body Material:
    Plastic
  • Foot Peg Location:
    Driver
  • Fork Guards:
    Yes
  • Frame:
    Steel
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    LED

PAINT & FINISH

  • Metallic:
    Yes

SEATS

  • Number Of Seats:
    1
  • Seat Height (in):
    31.5
  • Seat Height (mm):
    800.1
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Suspension Size (in):
    1.1
  • Front Suspension Size (mm):
    27
  • Front Suspension Type:
    Telescopic Fork
  • Front Travel (in):
    4.3
  • Front Travel (mm):
    109.2
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.4
  • Rear Travel (mm):
    86.4

TECHNICAL SPECIFICATIONS

  • Fuel Capacity (gal):
    1.4
  • Fuel Capacity (l):
    5.3
  • Fuel Capacity Reserve (gal):
    0.3
  • Fuel Capacity Reserve (l):
    1.1
  • Ground Clearance (in):
    6.5
  • Ground Clearance (mm):
    165.1
  • Height (in):
    42.7
  • Height (mm):
    1084.6
  • Length (ft):
    6.43
  • Length (ft/ft):
    6
  • Length (ft/in):
    5.2
  • Length (in):
    77.2
  • Length (mm):
    1961
  • Wet Weight (kg):
    116
  • Wet Weight (lbs):
    256
  • Wheelbase (in):
    49.4
  • Wheelbase (mm):
    1254.8
  • Width (in):
    31.7
  • Width (mm):
    805.2

TRANSMISSION

  • Number Of Speeds:
    4
  • Primary Drive (Rear Wheel):
    Chain
  • Transmission Type:
    Manual / Automatic Clutch

WHEELS & TIRES

  • Front Tire (Full Spec):
    IRC GP-5
  • Front Tire Aspect Ratio:
    90
  • Front Tire Speed Rating:
    P
  • Front Tire Width:
    80
  • Front Wheel Diameter:
    17
  • Rear Tire (Full Spec):
    IRC GP-5
  • Rear Tire Aspect Ratio:
    90
  • Rear Tire Speed Rating:
    P
  • Rear Tire Width:
    80
  • Rear Wheel Diameter:
    17
  • Tire Brand:
    IRC
  • Tube / Tubeless:
    Tubeless
  • Wheels Composition:
    Steel
